Thrill-Active(5kW) Solar & Inverter Package
Option A: 5kW Growatt Inverter with SRNE 10kWh Lithium Battery
Option B: 5kW Growatt Inverter with ITEL 10kWh Lithium Battery
What it can power:
- 2 units of 1 HP Inverter AC or 1unit of 2hp AC (on Gen Mode): two(2) units of 1hp Air conditioners can be used through the day but only 1unit of 1hp should be used after sunset for up to 3-5hrs only to avoid battery drain.
- Lightening: up to 10bulbs (≤ 200watts in total)
- Television(s): ≤ 300watts in total
- Laptops : up to 200watts (2-3units)
- Fan : up to 5 fans(≤ 250watts in total)
- Fridge : ≤ 200watts
- Freezer : ≤ 300watts (day use only 9:00 – 5:00pm if AC should be used at night for up to 5hrs)
- Washing Machine: ≤ 500watts in total, day use only recommended
- Pumping Machine: ≤ 1.5hp(1,119watts)NB: Other alternative priority loads can be substituted
Proceed to checkout and pay on an installment plan with the Klump payment option
Price range: ₦2,709,750.00 through ₦5,303,750.00
Description
Ideal User
Residential and commercial purposes.
This package is ideal for users with little above the average energy needs of a regular Nigerian household. Users in this category see a need to stay operational with or without the presence of alternative sources such as the national grid or mechanical power generating devices.
The goal of this user would be to maximize day time irradiation from the sun to power basic operational appliances for residential or commercial purposes like,2unit of 1 HP Inverter Air-condition, washing machine, pumping machine, freezer, fridge, lights, fan, TV while achieving close to Zero electricity bills during the day and loads like a few lights, fans ,Air conditioner, TV and refrigerator during the night; the users in this category can improve on their battery bank storage over time if more appliances would be needed to be operational at night.
Inverter Compartment Cost Breakdown
| GROWATT 5kW-48Vdc Hybrid Inverter 24months Warranty | ₦548,000 |
| Option A: SRNE 10kWh Lithium Battery 10.24kWh: 51.2V 200ah, 10years Warranty, 20years+ lifespan | ₦3,100,000 |
| Option B: ITEL 10kWh Lithium Battery 10.24kWh: 51.2V 200ah, 5years Warranty, 15years+ lifespan | ₦1,975,000 |
Breakers & Surge Protection kit
|
₦74,000 |
| Cables | ₦52,750 |
| Installation Cost To include fittings, screws and trunks | ₦60,000 |
| Option A Total | ₦3,834,750 |
| Option B Total | ₦2,709,750 |
Solar Compartment Cost Breakdown
| 5535Wp Solar Panel (9x 615W Jinko Solar Panel) 12years Warranty, Upto 30years Life Span | ₦1,242,000 |
| Solar Rack x4 | ₦48,000 |
Cables, Breakers & Surge Protection kit
|
₦71,000 |
| Installation Cost | ₦108,000 |
| Total | ₦1,469,000 |
| Option A: Total Installation Cost (solar+inverter) | ₦5,303,750 |
| Option B: Total Installation Cost (solar+inverter) | ₦4,178,750 |
NB:
- PV cables lengths are estimated for a single floor connection(i.e a bungalow), where extra floors exist, there would be an estimated 5meters addition in the length of PV Cables .
- Logistics cost would be based on location.
- AC Cable length are given based on close estimation, where it is in excess, Thrillhouse Limited would be willing to buy the excess (except when less than a meter), where it is in deficit, client would pay for the extra)
- Roof top installation has been assumed; any other location might require extra fabrication expense.
- Panel Installation increases by 1500 as floors increase
Additional information
| Options | Option A, Option B, Option A without Solar, Option B without Solar |
|---|
