Thrill-Prime(3.6kW) Solar & Inverter Package
What it can power:
-
Lightening: up to 6bulbs day and 3bulbs night (≤ 150watts in total)
-
Television : ≤ 100watts in total
-
Laptops : up to 200watts (3-4units for day time use)
-
Fan : up to 4 fans day and 2 at night (≤ 200watts in total)
-
Fridge : ≤ 200watts in total
-
Freezer : ≤ 200watts in total (day use only 9:00 – 5:00pm)
-
Washing Machine: ≤ 350watts in total (day use only 10:00 – 4:00pm)
-
Pumping Machine: ≤ 1.5hp(1,119watts); (day use only 12:00 – 3:00pm)
Ideal User
Residential(with high day time use and minimal night time use), Restaurants and eateries, offices, and Other commercial applications
This package is ideal for Tubular battery lovers with minimal night energy needs and relatively high energy demand during the day across basic appliances. The goal of this user would be to maximize day time irradiation from the sun to power basic operational appliances for residential or commercial purposes like washing machine, pumping machine, freezer, fridge, lights, fan, TV while achieving close to Zero electricity bills during the day and minimal loads like a few light, fan and TV only during the night; the users in this category can improve on their battery bank storage over time if more appliances would need to be operational at night
Inverter Compartment
| ITEL 3.6kW-24V Hybrid Inverter 24months Warranty, 5000Watts Maximum PV Power. Max PV input current 18A | ₦365,000 |
| 12v-220AH Ozoro/Adwin/Energos Battery x2 2years Warranty | ₦570,000 |
| Two Battery Rack | ₦22,000 |
| Breakers & Surge Protection kit 8 Way Distribution Box – ₦7500 Change Over Breaker (63amps) – ₦8,000 AC Digital Voltage Regulator(40amps) – ₦13,000 AC Surge Protector – ₦11,000 AC Input Breaker (25amps) – ₦2,500 AC Output Breaker (16amps) – ₦2,500 125amps Molded Breaker – ₦25,000 | ₦69,500 |
| Cables | ₦45,350 |
| Installation Cost To include fittings, screws and trunks | ₦40,000 |
| Total | ₦1,111,850 |
Solar Compartment
| 3025Wp Solar Panel (5x 605W Jinko P-Type) 12years Warranty, Upto 30years Life Span | ₦682,500 |
| Solar Rack x3 | ₦36,000 |
| Cables, Breakers & Surge Protection kit 4mm 2core PV Cable x15 – ₦45,000 4way Distribution Box – ₦5,000 20amps DC Breaker – ₦7,000 DC Surge Protector Device – ₦13,000 | ₦70,000 |
| Installation Cost | ₦60,000 |
| Total | ₦849,500 |
| Total Installation Cost (solar+inverter) | ₦1,961,350 |
NB:
- PV cables lengths are estimated for a single floor connection(i.e a bungalow), where extra floors exist, there would be an estimated 5meters addition in the length of PV Cables .
- Logistics cost would be based on location.
- AC Cable length are given based on close estimation, where it is in excess, Thrillhouse Limited would be willing to buy the excess (except when less than a meter), where it is in deficit, client would pay for the extra)
- Roof top installation has been assumed; any other location might require extra fabrication expense.
